    94v0 Temperature Sensor Controller PCB Board Dust Free SMT PCBA

    Ask Lasest Price
    Brand Name : FASTPCBA
    Model Number : OEM
    Certification : ISO13485, IATF16949, ISO9001
    Price : USD 0.1-3/ pcs
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100000pcs/month
    MOQ : No MOQ
    • Product Details
    • Company Profile

    94v0 Temperature Sensor Controller PCB Board Dust Free SMT PCBA

    94v0 Smt Assembly Pcba Pcb Design Printed Circuit Board Temperature Sensor Controller Pcb Board


    Specification of PCBA assembly


    ArticleDescriptionCapability
    MaterialLaminate materialsFR4, High TG FR4, High Frequency, Alum, FPC...
    Board CuttingNumber of layers1-48
    Min.thickness for inner layers
    (Cu thickness are excluded)
    0.003”(0.07mm)
    Board ThicknessStandard(0.1-4mm±10%)
    Min.Single/Double:0.008±0.004”
    4layer:0.01±0.008”
    8layer:0.01±0.008”
    Bow and twistno more than 7/1000
    Copper WeightOuter Cu weight0.5-4 0z
    Inner Cu weight0.5-3 0z
    DrillingMin size0.0078”(0.2mm)
    Drill deviation±0.002″(0.05mm)
    PTH hole tolerance±0.002″(0.005mm)
    NPTH hole tolerance±0.002″(0.005mm)
    Solder MaskColorGreen,white,black,red,blue…
    Min solder mask clearanace0.003″(0.07mm)
    Thickness(0.012*0.017mm)
    SilkscreenColorwhite,black,yellow,blue…
    Min size0.006″(0.15mm)
    Max Size of Finish Board700*460mm
    Surface FinishHASL,ENIG,immersion silver,immersion tin,OSP…
    PCB OutlineSquare,circle,irregular(with jigs)
    PackageQFN,BGA,SSOP,PLCC,LGA


    Delivery Time for PCB

    LayerPrototype

    Mass Productions

    (above 30 m2 )

    Quick TurnUnual Time
    224 hours3-4 days8-10 days
    448 hours5-6 days10-12 days
    672 hours6-8 days12-14 days
    896 hours8-10 days14-16 days
    10120 hours12-14 days16-18 days
    ............

    Delivery Time for PCBA

    Order ConditionsStandard Delivery DateThe fastest Delivery Date
    Prototype (<20 pcs)2 days8 hours
    Small Volum (20-100 pcs)3 days12 hours
    Medium Volum(100-1000 pcs)6 days24 hours
    Mass productions (>1000 pcs)Depends on BOMDepends on BOM


    Our PCB Sevices:


    * PCB fabrication.

    * PCB clone: reverse engineering, with all compoentns compeleted.

    * Turnkey PCBA: PCB+components+SMT and through-hole assembly+enclosure molding&housing


    Our Advantage:


    * Free programming and free functional test, free package.

    * High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% funtional test.

    * Professional service. ISO SMT and through hole assembly, over 20 years experience.

    * Certification for electronics: IATF16949, ISO13485, ISO9001
