FASTPCBA Is Professional 20 Years PCB / PCBA Manufactuer, Supply One-Stop Solution: PCB Manufacturing + Components Sourcing + PCB Assembly + Testing.
6 Years
| Ask Lasest Price | |
| Brand Name : | FASTPCBA |
| Model Number : | Pcba Electronics Manufacturing |
| Certification : | ISO13485, IATF16949, ISO9001 |
| Price : | USD 0.1-3/ pcs |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 100000pcs/month |
| MOQ : | No MOQ |
FASTPCBA is the professional pcb factory over 20 years, who has been audited by gemany bosch. With ISO9001, ISO13485, IATF16949 Certification., 5000㎡+ dust free and ESD protection smt workshop, FASTPCBA gets the favor of customers among military, aerospace, power communication, smart home, industrial control, automotive, medical.
FASTPCBA is well-known for precise and accutate pcb manufacturing and assembly capacibility among pcba industry with 70000 points/ h placement speed, can mount 0201 & 01005 devices, identify 0.25 pitch BGA and 0.2MM connectors, we can better satisfy high density, fine pith pcb assembly requirements.
FASTPCBA is the best one-stop pcba assembly supplier in china, it’s our continuous pursuit to better serve and creat more values for customers domestic and abroad.
TECHNICAL DATA:
| Article | Description | Capability |
| Material | Laminate materials | FR4, High TG FR4, High Frequency, Alum, FPC... |
| Board Cutting | Number of layers | 1-48 |
| Min.thickness for inner layers (Cu thickness are excluded) | 0.003”(0.07mm) | |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” | |
| 4layer:0.01±0.008” | ||
| 8layer:0.01±0.008” | ||
| Bow and twist | no more than 7/1000 | |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z | |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) | |
| PTH hole tolerance | ±0.002″(0.005mm) | |
| NPTH hole tolerance | ±0.002″(0.005mm) | |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) | |
| Thickness | (0.012*0.017mm) | |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) | |
| Max Size of Finish Board | 700*460mm | |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | |
| PCB Outline | Square,circle,irregular(with jigs) | |
| Package | QFN,BGA,SSOP,PLCC,LGA | |
Delivery Time for PCB
| Layer | Prototype | Mass Productions (above 30 m2 ) | |
| Quick Turn | Unual Time | ||
| 2 | 24 hours | 3-4 days | 8-10 days |
| 4 | 48 hours | 5-6 days | 10-12 days |
| 6 | 72 hours | 6-8 days | 12-14 days |
| 8 | 96 hours | 8-10 days | 14-16 days |
| 10 | 120 hours | 12-14 days | 16-18 days |
| ... | ... | ... | ... |
Delivery Time for PCBA
| Order Conditions | Standard Delivery Date | The fastest Delivery Date |
| Prototype (<20 pcs) | 2 days | 8 hours |
| Small Volum (20-100 pcs) | 3 days | 12 hours |
| Medium Volum(100-1000 pcs) | 6 days | 24 hours |
| Mass productions (>1000 pcs) | Depends on BOM | Depends on BOM |
With high pcb& pcba production capacibility, FASTPCBA mainly service for customers of industrial pcba, medical pcba, automotive pcba, smart home pcba, communication pcba, aerospace pcba and military pcba etc.
|
|
