High TG Printed Circuit Board 0.07mm Prototype PCB Assembly
FASTPCBA is an OEM manufacturer that focus on PCB manufacturing & PCB Assembly over 20 years. We have the capability to manufacture pcb ranging from basic single sided boards up to 48 layer multilayers, and provide one stop turnkey services, including PCB manufacture, PCB assembly, components source, function testing services and housing so on.We always provide high quality, technically advanced products within the customer’s timescales so that we can provide the best electronic services for you.This commitment, combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers PCB requirements – from front end engineering through to in time deliveries.
FASTPCBA has been selected as the “excellent partner of the year” by numerous well-known enterprises, and won many domestic and authorized certifications at home and abroad, such as Chinese high-tech project certification, ISO9001, ISO14001, ISO13485, IATF16949 quality management system standard and customized CE, UL, FCC and other product certifications according to the customer's requirements.
Capability for Printed Circuit Boards Assembly
Article | Description | Capability |
Laminate Materials | FR4, high TG FR4, high frequency, alum, FPC | |
Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers | 0.003”(0.07mm) | |
Board Thickness | Standard | (0.1-4mm±10%) |
Min. | Single/Double:0.008±0.004” | |
4layer:0.01±0.008” | ||
8layer:0.01±0.008” | ||
Bow and twist | no more than 7/1000 | |
Copper Weight | Outer Cu weight | 0.5-4 0z |
Inner Cu weight | 0.5-3 0z | |
Drilling | Min size | 0.0078”(0.2mm) |
Drill deviation | ±0.002″(0.05mm) | |
PTH hole tolerance | ±0.002″(0.005mm) | |
NPTH hole tolerance | ±0.002″(0.005mm) | |
Solder Mask | Color | Green,white,black,red,blue… |
Min solder mask clearanace | 0.003″(0.07mm) | |
Thickness | (0.012*0.017mm) | |
Silkscreen | Color | white,black,yellow,blue… |
Min size | 0.006″(0.15mm) | |
Component Sourcing | Yes | |
Tolerance of PCB | ±5% | |
Max Size of Finish Board | 700*460mm | |
MOQ | NO MOQ (1pcs) | |
Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | |
PCB Outline | Square,circle,irregular(with jigs) | |
Package | QFN,BGA,SSOP,PLCC,LGA | |
Sub-assembly | Plastic,metal,screen | |
Min Line/Space | 0.075/0.075mm | |
Packaging for =Printed Circuit Boards Assembly
1.Inner:
PCB: Vacuum Packing
PCBA: ESD Packing
2.Outer:
Standard export carton
3.Customized package.
|
|
